Electric Off-Road Motorcycles
SS05
10.5
Rated Power
kW
21
PK Power
kW
Hardcore off-roading, the favorite of extreme enthusiasts
Features
Feature 1:
Multiple Riding Modes
"ECO 58km/h
TRAIL 82km/h
SPORT 96km/h
TURBO 96km/h"
Feature 2:
Professional-grade reinforced front and rear shock absorbers, off-road performance comparable to gasoline motorcycles
Feature 3:
1395mm wheelbase, agile steering
320mm ground clearance
Specification
|
Type |
SS05 |
|
|
Complete Vehicle |
||
|
Motor Type |
PMSM Motor |
|
|
Battery |
NCM Lithium 73V50Ah |
|
|
Cooling System |
Air Cooling |
|
|
Drve Mode |
ECO58km/h |
|
|
Rated Power(kW) |
105 |
|
|
PKPower(kW) |
21 |
|
|
Maximum Torque(Nm) |
72075 |
|
|
Peak Speed(rpm) |
7500 |
|
|
Maximum Range(kM)@40Km/h |
129 |
|
|
MaxGrade Ability |
40° |
|
|
Acceleration time from0~50km/h(S) |
2.1 |
|
|
Front-Rear Weight Distribution |
49:51 |
|
|
Protection Level |
IP67 |
|
|
Weight(Kg) |
125 |
|
|
LengthWidth*Height(mm) |
2135×835×1210 |
|
|
Seat Height (mm) |
920 |
|
|
Ground Clearan ce (mm) |
340 |
|
|
Whelbase(mm) |
1490 |
|
|
Curb Weight(Kg) |
108 |
|
|
Maximum Load(Kg) |
150 |
|
|
Packing Size(mm) |
1800*460*1030 |
|
|
Quantity in 20'GP/40'HQ |
32(20GP)/64(40HQ) |
|
|
Sprocket Transmission Ratio |
1:3.26 |
|
|
Motor Gear Transmission Ratio |
1:2.941 |
|
|
Fame |
||
|
Type |
Twin-Wing Cage-Type Body |
|
|
Material |
16Mn Seamless Elliptical Special Steel |
|
|
Damping |
||
|
Brand |
Fastace |
|
|
Fork |
L880-051*043 |
|
|
Damping Adjustment |
Petal-shaped manual damping adjustable knob |
|
|
Fork Travel |
245mm |
|
|
Shodk Absorber |
L455-016 |
|
|
Shock Travel |
75mm |
|
|
Tire |
||
|
Brand |
Farstar |
|
|
Type |
Off-road tire |
|
|
Rim |
Aluminum alloy spoke structure |
|
|
Front Tire |
80/100-21 |
|
|
Rear Tire |
110/90-18 |
|
|
Brakes |
||
|
Type |
Disc Brakes (Front dual pump, rear dual pump) |
|
|
Front Brakes |
⊗270 mm-3mm |
|
|
Rear Brakes |
⑦240 mm-4mm |
|
|
Material |
12Cr13 martensitic high-temperature steel |
|
|
Pattern |
Sunburst pattern ventilation disc |
|
|
Handlebar |
||
|
Material |
TPE |
|
|
Protecion Level |
IP66 |
|
|
Throttle Rotation Angle |
65° |
|
|
Drive Modes |
||
|
Modes Name |
ECO/TRAIL/SPORT/TURBO/REVERSE |
|
|
Meter |
||
|
Display Type |
4.3"TT Color Screen |
|
|
Brightness |
1200 cd/m |
|
|
Protection Level |
IP66 |
|
|
Certification |
CE/ROHS/FCC |
|
|
Battery |
||
|
Rated Voltage (V) |
73 |
|
|
Energy Storage |
3.7 kWh |
|
|
Driving Time |
ECO Modes |
4 hours |
|
Aggressive Mode |
1 hours |
|
|
Charging Time |
0~1009%0~10096 |
5.5hours |
|
Color Scheme |
||
|
Name |
Lightning Yellow、 Space Silver、Flame Red、Pearl white、Ony×Black |
|
FAQ
Does the vehicle have certification?
Golf carts are off-road vehicles, so the entire vehicle does not require certification. In Europe and America, only components need eMark certification, and the components must meet the certification requirements.
Does the vehicle have CarPlay connectivity?
Yes, it can connect to your phone via Bluetooth.
Are the battery capacities interchangeable?
The 105Ah/155Ah/205Ah capacities are interchangeable.
After-sales service policy
The battery, motor, and charger are covered by a one-year warranty. Other components are not covered by the warranty. Repairs will be primarily conducted via video communication and on-site guidance, depending on the region.
